Access
Hydrophilic Introducer Sheath Kit
Polymer guidewire with hydrophilic coating, 5F to 8F.
The DXQ series pairs the introducer sheath with a hydrophilic-coated polymer guidewire for easier passage through tortuous or spastic radial arteries, and adds a purpose-designed valve against backflow and air entry.
- FDA product code
- DYB
- Device listing
- D577326
- 510(k)
- K222184
- Manufacturer
- Beijing Demax Medical Technology Co., Ltd.
Features
- Hydrophilic-coated polymer guidewire
- Enhanced pushability and flexibility
- Enlarged inner diameter for an ultra-smooth dilator-to-sheath transition
- Smooth transition section reduces trauma to the vessel
- Valve designed to prevent blood backflow and air entry
Ordering information
| Ref. No. | French size | Sheath length (cm) | Guidewire | Needle |
|---|---|---|---|---|
| DXQ05082520 | 5F | 8 | 0.025 in | 20G |
| DXQ05112520 | 5F | 11 | 0.025 in | 20G |
| DXQ06082520 | 6F | 8 | 0.025 in | 20G |
| DXQ06112520 | 6F | 11 | 0.025 in | 20G |
| DXQ07082520 | 7F | 8 | 0.025 in | 20G |
| DXQ07112520 | 7F | 11 | 0.025 in | 20G |
| DXQ08082520 | 8F | 8 | 0.025 in | 20G |
| DXQ08112520 | 8F | 11 | 0.025 in | 20G |
Specifications from the current Zenith 11 Medical catalog. Confirm configuration and sterility requirements at time of order. Prescription use only; refer to the instructions for use.
